5 Axis CNC Router/Engraving machine
Application:
This CNC Router, configured with high quality spare parts. It can be used to cut or engrave on plastic, acrylic, composite panel, wood, MDF, aluminum, copper, etc., widely used in advertising and woodworking industries.
Mold industry: Various large metalloid moulds, especially suitable for automotive foam mold, wooden ship model, wooden model aviation, rail wooden mold and wooden mold train.
Instrument industry: 3D surface engraving and shape cutting of large-scale instruments.
Keywords: 5 axis CNC machine, CNC Milling Machine, CNC Router, CNC Router Machine, Wood CNC Router, wood engraving machine, woodworking CNC router
|
Name |
5 AXIS CNC Router |
| Configuration Description | l Taiwan SINTEC 5 axis control system, with RT/CP Space compensation functionl UK powermill Softwarel Seamless and welded steel with aging & tempering treatment Working area XYZ: x- 4000 mm, y -3000mm, z -1250mml With T-slot clamp tablel 5 sets Japanese Yaskawa servo motors , powerful twisting force and long time working（one set with brake function)l Italy HSD-10KW（0-18000rpm）,with HSK ER32knife handle，diameter 25mm
l Italy HSD 5 Axis head； l 8 tools automatic changing & Turntable style tool magazine l Delta 11KW inverter； l Japan NSK P4level bearing l German flexible lotus coupling； l Electrical combination: France Schneider l China chengtai braking resistor l Worktable load table:1000kg； l Max travel speed:80m/min； l Max working speed:40min/minutes； l Total 12kw,3P,380V；
|
Model Description
Parameter
|
|
Series |
5 AXIS CNC Router |
|
1 |
X/Y/Z Axis Travelling size |
x – 4000 mm, y – 3000mm , z – 1250mm |
|
2 |
A/C Axis |
A:±120°,C：±245° |
|
3 |
Transmission |
Y helical rack and X/Z pinion drive |
|
4 |
Table structure |
Aluminum profile ( with T-slots) |
|
5 |
Spindle power |
10.0 KW HSD |
|
6 |
Spindle speed |
22000 r/min |
|
7 |
Travelling speed |
60 / 30m/min |
|
8 |
Working speed |
30m/min |
|
9 |
Tool magazine |
Turntable style tool unit |
|
10 |
Tool slots |
8 |
|
11 |
Driving system |
Yaskawa |
|
12 |
Voltage |
AC380/3PH/50HZ |
|
13 |
Controller |
Syntec |
